Basic Info.

Model NO.	PH-3015
Transport Package	Plywood
Specification	CE
Trademark	Sinowon
Origin	Dongguan
HS Code	90318020
Production Capacity	30 Sets/Month

Product Description

High Accuracy Horizontal Video Projector PH-3015
Features:

1. The lifting system adopts linear guide rail and precision screw drive, which makes the lift drive more comfortable and stable;
2. With precision toothless rod and fast movement locking device, ensure return error is within 2um;
3. High accuracy A optical scale and precision working stage, ensure machine accuracy is within 3+L/200 um;
4. HD zoom lens and HD color digital camera, ensure clear image without distortion;
5. With programmable surface 4-ring 8-division LED cold light and contour LED parallel illumination, it can control the brightness of the 4-ring 8-division independently;
6. With powerful iMeasuring2.1 software system , to enhance the control quality;
7. Optional imported contact probes and 3D measuring software, it can help upgrade the machine to be coordinate measuring machine;
8. Optional FexQMS measurement data analysis and real-time monitor software, enhance process control, reduce material consumption.

Specification:

Product Name		Horizontal Video Projector
Model		PH-3015
Code#		#542-310
Working Stage Travel		300X150mm
Focusing Travel		120mm (Focus)
Measurement Accuracy*		≤3+L/200um
Resolution		0.0005mm
Load Capacity		25kg
CCD		HD700 TVL Color CCD
Zoom Lens**		HD 6.5X Detented Zoom Lens
		Optical Magnification:0.7X-4.5X; Video Magnification:26X~172X(21.5"monitor)
Field of View (mm)	Lens Magnification	0.7X	1X	2.0X	3.0X	4X	4.5X
Diagonal*Horizontal*Vertical 1/3"CCD		8.57x6.86x5.14	6x4.8x3.6	3x2.4x1.8	2x1.6x1.2	1.5x1.2x0.9	1.33x1.07x0.8
Illuminating System (Software Control)		Surface: Adjustable 4-ring 8-division 0~255-grade LED Cold Illumination
		Contour: LED Parallel illumination
		LED Laser navigation illumination
Working Environment		Temp:20ºC±2ºC,Temp Variation<2ºC/hr, Humidity:30%-80%RH,Vibration<0.002g,< 15HZ
Measurement Software		iMeasuring 2.1
System		Support XP, WIN7, WIN8,WIN10 32/64 Bit
Power		AC110V/60Hz; 220V/50Hz,600W
Dimension		1200 x 600 x1500mm
Weight		350kg

* L is measuring length,unit is mm, the mechanical accuracy of Z-axis and focus accuracy is greatly related to the surface of the workpiece.
** Magnification is approximate value, it is related to the dimension of monitor and resolution.
Customers can choose 0.5X or 2X optional objective, and realize image magnification: 13X~86X or 52X~344X.
